| Model |
Number |
CS-51V3A-PB156AN/CS-61V3A-E2N |
| Rated volt and frequency |
Ph-V-Hz |
220-240/50 |
| Cooling |
Cooling capacity |
W |
5100 (2800 ~ 5500) |
| Cooling power input |
W |
1585 (720 ~ 1880) |
| Heating current input |
A |
6.9 (3.2 ~ 8.5) |
| EER |
w/w |
3.22 |
| Heating |
Heating capacity |
W |
5200 (2900 ~ 5700) |
| Heating power input |
W |
1525 (730 ~ 1920) |
| Heating current Input |
A |
6.7 (2.8 ~ 8.7) |
| COP |
w/w |
3.41 |
| Max. input consumption |
W |
2800 |
| Max. current |
A |
13.5 |
| Compressor |
Model |
|
ATD141RDPA8JT |
| Type (Rotary Piston) |
|
Rotary |
| Brand |
|
Highly |
| Indoor |
Fan Motor |
Model |
|
YDK-27-4 A6 |
| Power input |
W |
56 |
| Capacity |
uF |
1.8 |
| Indoor Fan Speed RPM |
r/min |
1300/1150/1000 |
|
Indoor Fan Dia x Lenght |
mm |
102 x 707 |
| Indoor air circulation |
m³/h |
850 |
| Indoor noise sound pressure level |
dB(A) |
42~46 |
| Dimension (L x W x H) |
mm |
900 x 292 x 215 |
| Packing (L x W x H) |
mm |
983 x 377 x 300 |
| Net/Gross weight |
Kg |
14/17 |
| Outdoor |
Fan Motor |
Model |
|
YDK-40-6A 1 H2 |
| Power Input |
W |
103 |
| Capacity |
uF |
3 |
| Outdoor Fan Speed RPM |
r/min |
870/600 |
| Outdoor Fan |
Dia x High |
mm |
415 |
|
Tube pitch x row pitch x Fin |
mm |
21*18.19*1.6 |
| Fin type |
mm |
Blue open window hydrophilic fin |
| Tube outside dia and type |
mm |
Ø7.0×0.25+0.18 Internal thread tube |
| Coil length x height x width |
mm |
798 x 546 x 36.38 |
| Noise Level |
dB/(A) |
55 |
| Dimension (L x W x D) |
mm |
850 x 295 x 605 |
| Packing (L x W x H) |
mm |
995 x 415 x 690 |
| Net/Gross weight |
Kg |
40/45 |
| Refrigerant Type /weight |
g |
R410a/1420g |
| Design pressure (Hi/Low) |
MPa |
4.2/1.2 |
| Refrigerant Piping |
Liquid side/Gas side/Length |
mm |
6.35/12.7/3000 (1/4″+1/2″) |
| Max difference in level |
m |
15/5 |
